Description

Dahua 4-Channel 1080N High-Definition CCTV Kit

Take control of your property’s surveillance with the Dahua 4-Channel HD-CVI Security Kit. This all-in-one surveillance solution is designed to provide high-definition monitoring for homes and small businesses. Featuring 2MP (1080p) Dome Cameras, this kit delivers crisp video quality and reliable performance, ensuring you never miss a detail.

Equipped with a 1TB Surveillance Hard Drive, the system is ready to record right out of the box, offering weeks of storage using advanced video compression technology.

---

Kit Components

• Dahua 4-Channel XVR: A compact, high-performance recorder that supports 1080N/720P resolution. It features smart search functions and remote mobile viewing.

• 4x 2MP HD Dome Cameras: Discreet, ceiling-mount cameras providing high-definition 1080p video with excellent night vision capabilities.

• 1TB Surveillance HDD: Pre-installed, high-reliability hard drive optimized for 24/7 video recording.

• 100m Cat5 Cable: High-quality cabling to provide flexible installation distances across your premises.

• Installation Accessories: Includes 8x Video Baluns and 4x DC Power Connectors to run video and power over the Cat5 cable.

• Power & Mounting: Includes a dedicated Power Supply Unit (PSU) and 4x Camera Junction Boxes (Nests) to neatly house and protect your cable connections.

---

Key Features & Benefits

• Full HD 1080p Monitoring: Clear, high-definition video allows for better identification of faces, license plates, and incidents.

• Smart IR Night Vision: Integrated infrared LEDs allow the cameras to see in total darkness (up to 20m), automatically adjusting intensity to prevent overexposure of close-up objects.

• Mobile Remote Viewing: Connect your XVR to the internet and use the DMSS App (iOS/Android) to view live footage or playback recordings from anywhere in the world.

• H.265+ Compression: Saves up to 70% on storage space and bandwidth compared to older systems, allowing your 1TB drive to hold more footage without sacrificing quality.

• Motion Detection Alerts: Configure the system to record only when movement is detected and receive instant push notifications to your smartphone.

• Hybrid Technology: The XVR is “Penta-brid,” meaning it is compatible with HDCVI, AHD, TVI, CVBS, and IP video inputs for maximum flexibility.

---

Technical Specifications

Feature	Specification
Recorder Resolution	1080N / 720P
Camera Sensor	2 Megapixel CMOS
Night Vision Range	Up to 20 Meters
Storage	1TB SATA HDD (Included)
Video Compression	H.265+ / H.265 / H.264+ / H.264
Remote Access	DMSS App (Mobile), SmartPSS (PC)
Cabling	100m Cat5 with Baluns

---

Why Choose This Kit?

This Dahua kit is the perfect “Security-in-a-Box” solution. By using Cat5 cable with Video Baluns, you have the flexibility to cut cables to the exact length needed for your building, avoiding messy coils of pre-made wire. The inclusion of Camera Nests ensures a professional, vandal-resistant finish by hiding all plugs and connections behind the camera base.

Note: This kit is designed for connection to any standard TV or Monitor via HDMI or VGA (Monitor not included).
